The A2512 accelerometer has been designed for dynamic structural testing in tough field conditions where long cable lengths are required.
These accurate, rugged, and fully-weatherproofed integrated MEMS sensors can be used from zero to medium frequency applications that require low noise and reliable long-term stability.
Available in uniaxial, biax,al, and triaxial versions, each model can be installed very quickly and is available in ranges between ±2g and ±100g.
Features
Completely reusable
Designed to exceed IP67
Nitrogen gas damped
High stability
Low power requirements
Various mounting options available
Industrial cable, custom lengths
N.I.S.T. traceable calibration available
9-30 Vdc input voltage range
High differential output (±4.0 Vdc)
Responds down to 0 Hz
| Specifications |
|
|
|
|
|
|
| UNIAXIAL MODELS |
UA2512-002 |
UA2512-005 |
UA2512-010 |
UA2512-025 |
UA2512-050 |
UA2512-100 |
| BIAXIAL MODELS |
BA2512-002 |
BA2512-005 |
BA2512-010 |
BA2512-025 |
BA2512-050 |
BA2512-100 |
| TRIAXIAL MODELS |
TA2512-002 |
TA2512-005 |
TA2512-010 |
TA2512-025 |
TA2512-050 |
TA2512-100 |
| RANGE (g) |
±2 |
±5 |
±10 |
±25 |
±50 |
±100 |
| FREQUENCY RESPONSE [NOMINAL, 3dB] (Hz) |
0-300 |
0-400 |
0-600 |
0-900 |
0-1200 |
0-1400 |
| DIFFERENTIAL SENSITIVITY (mV/g) |
1000 |
400 |
200 |
80 |
40 |
20 |
| EXCITATION VOLTAGE |
9-30 Vdc |
| OUTPUT |
±2.0 Vdc FS |
| OPERATING TEMPERATURE |
-58° to +176 °F (-50° to +80 °C) |
| BIAXIAL |
2.45 in x 1.80 in x 1.10 in (62.2 mm x 45.7 mm x 27.9 mm) |
| HOUSING |
Machined 6061 Aluminium Alloy |
| CORROSION RESISTANCE |
Hard Anodized Clear (MIL-A-8625 Type III) |
| WEATHER PROTECTION |
Designed to exceed IP67 |
